- Safer: The unique KickbackStop reduces the risk of injury caused by kickback during sawing or plunge-cutting into the workpiece.
- Dive deeper: Greater cutting depth, at the same size and weight as the TS 55 F
- Versatile: Option to combine with the tried-and-tested guide rails and now with the FSK cross-cutting guide rails too
- Constant: EC-TEC motor in combination with the thin kerf saw blades ensures work progresses quickly whilst requiring less effort
- Precise: Simple, precise and repeatable mitre cuts can be achieved by setting mitre angles from -1° to 47°
- Convenient: The FastFix spindle stop and sophisticated design make it extremely easy to change the saw blade
- Best orientation: A transparent sliding viewing window provides a good view of the saw blade
Main applications
- Precise plunge cuts in materials up to 60 mm thick
- Cutting interior doors to length using guide rail and circular saw
- Cutting recesses in doors and kitchen worktops
- Cutting chipboard to size (chipboard, veneered and plastic-coated panels)
- Cross cuts with the FSK cross-cutting guide rail (floor panels, slats, boards)
- Manufacturing expansion joints in parquet flooring and false joints
Technical Data
Power consumption 1 500 W
Idle engine speed 3 000 – 6 800 min⁻¹
Saw blade diameter 168.00 mm
Angular range -1 – 47 °
Cutting depth 0 – 62 mm
Cutting depth 45° 45 mm
Dust extraction connection diameter 27/36 mm
Cable length 4.00 m
Product weight 4.70 kg
transportgewicht 7.00 kg
Drive type Mains
